Productdetails:
Betalen & Verzenden Algemene voorwaarden:
|
Certificering: | CE | gewicht: | 850kg |
---|---|---|---|
Merk: | Bitzer | Type: | Compressor |
Garantie: | 1 jaar | Toepassing: | Koelingsdelen |
Hoog licht: | Koude Zaal Compacte Schroefcompressor,Compacte de Schroefcompressor van CSH,CSH8553-110-38p Semi Hermetische Compressor |
1. Productinleiding
Flexibel
· Dubbele capaciteitscontrole: de schakelaar tussen stadium 4 en naadloze capaciteit controleert – zonder het werk van de compressoraanpassing
· Zuiging en druk de schakelaars kunnen in toename worden geroteerd 90°
Outstandingly efficiënt hoog rendementprofiel dankzij
· Geavanceerde meetkunde
· Hoge starheid
· Gepatenteerd productieproces voor maximumprecisie
· Hoge randsnelheid
2. Productparameter (Specificatie)
schroefcompressor | ||
Model | CFH Displ 60 Herz | Motor HP |
Csh6553-50 | 165 | 50 |
CSH6563- 60 | 205 | 60 |
CSH7553- 70 | 238 | 70 |
CSH7563-80 | 274 | 80 |
CSH7573-90 | 311 | 90 |
CSH8553-110 | 380 | 110 |
CSH8563-125 | 433 | 125 |
CSH8573-140 | 495 | 140 |
CSH9553-180 | 645 | 180 |
CSH9563-210 | 742 | 210 |
CSH9573-240 | 844 | 240 |
CSH9583-280 | 971 | 280 |
CSH9593-300 | 1098 | 300 |
3.Production details
Si | IP | |
Verplaatsing (2900 t/min 50 Herz) | 170 m ³ /h | 6007 CFH |
Verplaatsing (3500 t/min 60 Herz) | 205 m ³ /h | 7246 CFH |
Gewicht | 325 kg | 717 pond |
Maximum, druk (LP/HP) | 19/28 bar | 275/400 psi |
De lijn van de verbindingszuiging | 54mm-2 1/8“ | 54mm-2 1/8“ |
De lijn van de verbindingslossing | 42mm-1 5/8“ | 42mm-1 5/8“ |
Motorvoltage (meer op verzoek) | 380-415V pw-3-50HZ | 440-480V pw-3-60HZ UL |
Maximum werkende stroom | 108.0 A | 108.0 A |
Windende Radio | 50/50 | 50/50 |
Beginnende stroom (gesloten Rotor) | 269.0 EEN D/508.0 DD |
269.0 EEN D/508.0 DD |
